I’ve been working on Group Policy deployment in Samba. Samba master (not released) currently now installs a samba-gpupdate script, which works similar to gpupdate on Windows (currently in master it defaults to –force, but that changes soon).
Group Policy can also apply automatically by setting the smb.conf option ‘apply group policies’ to yes.
Recently, I’ve written a client side extension (CSE) which applies samba smb.conf settings to client machines. I’ve also written a script which generates admx files for deploying those settings via the Group Policy Management Console.

You can view the source, and follow my progress here: https://gitlab.com/samba-team/samba/merge_requests/32

As part of SUSE Hackweek 17 I decided to work on a fully fledged docker registry mirror.

You might wonder why this is needed, after all it’s already possible to run a docker distribution (aka registry) instance as a pull-through cache. While that’s true, this solution doesn’t address the needs of more “sophisticated” users.

The problem

Based on the feedback we got from a lot of SUSE customers it’s clear that a simple registry configured to act as a pull-through cache isn’t enough.

Let’s go step by step to understand the requirements we have.

On-premise cache of container images

First of all it should be possible to have a mirror of certain container images locally. This is useful to save time and bandwidth. For example there’s no reason to download the same image over an over on each node of a Kubernetes cluster.

A docker registry configured to act as a pull-through cache can help with that. There’s still need to warm the cache, this can be left to the organic pull of images done by the cluster or could be done artificially by some script run by an operator.

Unfortunately a pull-through cache is not going to solve this problem for nodes running inside of an air-gapped environment. Nodes operated in such an environment are located into a completely segregated network, that would make it impossible for the pull-through registry to reach the external registry.

Retain control over the contents of the mirror

Cluster operators want to have control of the images available inside of the local mirror.

For example, assuming we are mirroring the Docker Hub, an operator might be fine with having the library/mariadb image but not the library/redis one.

When operating a registry configured as pull-through cache, all the images of the upstream registry are at the reach of all the users of the cluster. It’s just a matter of doing a simple docker pull to get the image cached into the local pull-through cache and sneak it into all the nodes.

Moreover some operators want to grant the privilege of adding images to the local mirror only to trusted users.

There’s life outside of the Docker Hub

The Docker Hub is certainly the most known container registry. However there are also other registries being used: SUSE operates its own registry, there’s Quay.io, Google Container Registry (aka gcr) and there are even user operated ones.

A docker registry configured to act as a pull-through cache can mirror only one registry. Which means that, if you are interested in mirroring both the Docker Hub and Quay.io, you will have to run two instances of docker registry pull-through caches: one for the Docker Hub, the other for Quay.io.

This is just overhead for the final operator.

A better solution

During the last week I worked to build a PoC to demonstrate we can create a docker registry mirror solution that can satisfy all the requirements above.

I wanted to have a single box running the entire solution and I wanted all the different pieces of it to be containerized. I hence resorted to use a node powered by openSUSE Kubic.

I didn’t need all the different pieces of Kubernetes, I just needed kubelet so that I could run it in disconnected mode. Disconnected means the kubelet process is not connected to a Kubernetes API server, instead it reads PODs manifest files straight from a local directory.

The all-in-one box

I created an openSUSE Kubic node and then I started by deploying a standard docker registry. This instance is not configured to act as a pull-through cache. However it is configured to use an external authorization service. This is needed to allow the operator to have full control of who can push/pull/delete images.

I configured the registry POD to store the registry data to a directory on the machine by using a Kubernetes hostPath volume.

On the very same node I deployed the authorization service needed by the docker registry. I choose Portus, an open source solution created at SUSE a long time ago.

Portus needs a database, hence I deployed a containerized instance of MariaDB on the same node. Again I used a Kubernetes hostPath to ensure the persistence of the database contents. I placed both Portus and its MariaDB instance into the same POD. I configured MariaDB to listen only to localhost, making it reachable only by the Portus instance (that’s because they are in the same Kubernetes POD).

I configured both the registry and Portus to bind to a local unix socket, then I deployed a container running HAProxy to expose both of them to the world.

The HAProxy is the only container that uses the host network. Meaning it’s actually listening on port 80 and port 443 of the openSUSE Kubic node.

I went ahead and created two new DNS entries inside of my local network:

• registry.kube.lan: this is the FQDN of the registry
• portus.kube.lan: this is the FQDN of portus

I configured both the names to be resolved with the IP address of my container host.

I then used cfssl to generate a CA and then a pair of certificates and keys for registry.kube.lan and portus.kube.lan.

Finally I configured HAProxy to:

• Listen on port 80 and 443.
• Automatically redirect traffic from port 80 to port 443.
• Perform TLS termination for registry and Portus.
• Load balance requests against the right unix socket using the Server Name Indication (SNI).

By having dedicated FQDN for the registry and Portus and by using HAProxy’s SNI based load balancing, we can leave the registry listening on a standard port (443) instead of using a different one (eg: 5000). In my opinion that’s a big win, based on my personal experience having the registry listen on a non standard port makes things more confusing both for the operators and the end users.

Once I was over with these steps I was able to log into https://portus.kube.lan and perform the usual setup wizard of Portus.

Mirroring images

We now have to mirror images from multiple registries into the local one, but how can we do that?

Sometimes ago I stumbled over this tool, which can be used to copy images from multiple registries into a single one. While doing that it can change the namespace of the image to put it all the images coming from a certain registry into a specific namespace.

I wanted to use this tool, but I realized it relies on the docker open-source engine to perform the pull and push operations. That’s a blocking issue for me because I wanted to run the mirroring tool into a container without doing nasty tricks like mounting the docker socket of the host into a container.

Basically I wanted the mirroring tool to not rely on the docker open source engine.

At SUSE we are already using and contributing to skopeo, an amazing tool that allows interactions with container images and container registries without requiring any docker daemon.

The solution was clear: extend skopeo to provide mirroring capabilities.

I drafted a design proposal with my colleague Marco Vedovati, started coding and then ended up with this pull request.

While working on that I also uncovered a small glitch inside of the containers/image library used by skopeo.

Using a patched skopeo binary (which include both the patches above) I then mirrored a bunch of images into my local registry:

$ skopeo sync --source docker://docker.io/busybox:musl --dest-creds="flavio:password" docker://registry.kube.lan
$ skopeo sync --source docker://quay.io/coreos/etcd --dest-creds="flavio:password" docker://registry.kube.lan

The first command mirrored only the busybox:musl container image from the Docker Hub to my local registry, while the second command mirrored all the coreos/etcd images from the quay.io registry to my local registry.

Since the local registry is protected by Portus I had to specify my credentials while performing the sync operation.

Running multiple sync commands is not really practical, that’s why we added a source-file flag. That allows an operator to write a configuration file indicating the images to mirror. More on that on a dedicated blog post.

At this point my local registry had the following images:

• docker.io/busybox:musl
• quay.io/coreos/etcd:v3.1
• quay.io/coreos/etcd:latest
• quay.io/coreos/etcd:v3.3
• quay.io/coreos/etcd:v3.3
• … more quay.io/coreos/etcd images …

As you can see the namespace of the mirrored images is changed to include the FQDN of the registry from which they have been downloaded. This avoids clashes between the images and makes easier to track their origin.

Mirroring on air-gapped environments

As I mentioned above I wanted to provide a solution that could be used also to run mirrors inside of air-gapped environments.

The only tricky part for such a scenario is how to get the images from the upstream registries into the local one.

This can be done in two steps by using the skopeo sync command.

We start by downloading the images on a machine that is connected to the internet. But instead of storing the images into a local registry we put them on a local directory:

$ skopeo sync --source docker://quay.io/coreos/etcd dir:/media/usb-disk/mirrored-images

This is going to copy all the versions of the quay.io/coreos/etcd image into a local directory /media/usb-disk/mirrored-images.

Let’s assume /media/usb-disk is the mount point of an external USB drive. We can then unmount the USB drive, scan its contents with some tool, and plug it into computer of the air-gapped network. From this computer we can populate the local registry mirror by using the following command:

$ skopeo sync --source dir:/media/usb-disk/mirrored-images --dest-creds="username:password" docker://registry.secure.lan

This will automatically import all the images that have been previously downloaded to the external USB drive.

Pulling the images

Now that we have all our images mirrored it’s time to start consuming them.

It might be tempting to just update all our Dockerfile(s), Kubernetes manifests, Helm charts, automation scripts, … to reference the images from registry.kube.lan/<upstream registry FQDN>/<image>:<tag>. This however would be tedious and unpractical.

As you might know the docker open source engine has a --registry-mirror. Unfortunately the docker open source engine can only be configured to mirror the Docker Hub, other external registries are not handled.

This annoying limitation lead me and Valentin Rothberg to create this pull request against the Moby project.

Valentin is also porting the patch against libpod, that will allow to have the same feature also inside of CRI-O and podman.

During my experiments I figured some little bits were missing from the original PR.

I built a docker engine with the full patch applied and I created this /etc/docker/daemon.json configuration file:

{
  "registries": [
    {
      "Prefix": "quay.io",
      "Mirrors": [
        {
          "URL": "https://registry.kube.lan/quay.io"
        }
      ]
    },
    {
      "Prefix": "docker.io",
      "Mirrors": [
        {
          "URL": "https://registry.kube.lan/docker.io"
        }
      ]
    }
  ]
}

Then, on this node, I was able to issue commands like:

$ docker pull quay.io/coreos/etcd:v3.1

That resulted in the image being downloaded from registry.kube.lan/quay.io/coreos/etcd:v3.1, no communication was done against quay.io. Success!

What about unpatched docker engines/other container engines?

Everything is working fine on nodes that are running this not-yet merged patch, but what about vanilla versions of docker or other container engines?

I think I have a solution for them as well, I’m going to experiment a bit with that during the next week and then provide an update.

Show me the code!

This is a really long blog post. I’ll create a new one with all the configuration files and instructions of the steps I performed. Stay tuned!

In the meantime I would like to thank Marco Vedovati, Valentin Rothberg for their help with skopeo and the docker mirroring patch, plus Miquel Sabaté Solà for his help with Portus.

Ever since the dawn of times, we’ve been crafting pixel perfect icons, specifically adhering to the target resolution. As we moved on, we’ve kept with the times and added these highly detailed high resolution and 3D modelled app icons that WebOS and MacOS X introduced.

As many moons have passed since GNOME 3, it’s fair to stop and reconsider the aesthetic choices we made. We don’t actually present app icons at small resolutions anymore. Pixel perfection sounds like a great slogan, but maybe this is another area that dillutes our focus. Asking app authors to craft pixel precise variants that nobody actually sees? Complex size lookup infrastructure that prominent applications like Blender fail to utilize properly?

Blender: Linux is the only platform with botched app icon.

For the platform to become viable, we need to cater to app developers. Just like Flatpak aims to make it easy to distribute apps, and does it in a completely decetralized manner, we should emphasize with the app developers to design and maintain their own identity.

Having clear and simple guidelines for other major platforms and then seeing our super complicated ones, with destructive mechanisms of theming in place, makes me really question why we have anyone actually targeting GNOME.

The irony of the previous blog post is not lost on me, as I’ve been seduced by the shading and detail of these highres artworks. But every day it’s more obvious that we need to do a dramatic redesign of the app icon style. Perhaps allowing to programatically generate the unstable/nightlies style. Allow a faster turnaround for keeping the style contemporary and in sync what other platforms are doing. Right now, the dated nature of our current guidelines shows.

Time to murder our darlings…

The Libyui REST API Project

I spent the 17th HackWeek working on the previous project - libyui REST API for testing the applications.

You can read some rationale in the blog post for the previous Hackweek.

In short it allows inspecting the current user interface of a programm via a REST API. The API can be used from many testing frameworks, there is a simple experimental wrapper for the Cucumber framework.

Examples

The REST API can be also used directly from the command line, this is a short example how it works:

First start an YaST module, specify the port which will be used by the REST API:

YUI_HTTP_PORT=14155 /usr/sbin/yast timezone

Inspecting with cURL

Then you can inspect the current dialog directly from the command line

# curl http://localhost:14155/dialog
{
  "class" : "YDialog",
  "hstretch" : true,
  "type" : "main",
  "vstretch" : true,
  "widgets" :
  [
    {
      "class" : "YVBox",
      "help_text" : "...",
      "hstretch" : true,
      "id" : "WizardDialog",
      "vstretch" : true,
      "widgets" :
      [
        {
          "class" : "YReplacePoint",
          "id" : "topmenu",
...

You can also send some action, like pressing the Cancel button:

curl -i -X POST "http://localhost:14155/widgets?action=press_button&label=Cancel"

Using the Cucumber Wrapper

The experimental Cucumber wrapper allows writing the tests in a native English language. The advantage is that people not familiar with YaST internals can write the tests easily. And even non-developers could use it.

Feature: To install the 3rd party packages I must be able to add a new package
  repository to the package management.

  Scenario: Adding a new repository

    Given I start the "/usr/sbin/yast2 repositories" application
    Then the dialog heading should be "Configured Software Repositories"

    When I click button "Add"
    Then the dialog heading should be "Add On Product"

    When I click button "Next"
    Then the dialog heading should be "Repository URL"
    Then continue...

What Has Been Improved

Here is a short summary what has been improved since the last HackWeek.

More Details and More Actions

The HTTP server now returns more details about the UI like the table content, the combo box values, etc… Maybe something is still missing but adding more details for specific widgets should be rather easy.

Also some more actions have been added, now it is possible to set a combo box value or select the active radio button via the REST API.

Processing the Server Requests

Originally the HTTP server was processing the data only when the UI.UserInput call was waiting for the input. That was quite limiting as the HTTP requests might have timed out before before reaching that point.

Now the server is responsive also during the other UI calls and even when there is no UI call processed at all. So the API is not blocked when YaST is doing some time consuming action like installing packages. The response now contains the current progress state as displayed in the UI.

Moreover it even works when there is no UI dialog open yet!

# cat ./test.rb
sleep(30)
# YUI_HTTP_PORT=14155 /usr/sbin/yast2 ./test.rb &
[1] 23578
# curl -i "http://localhost:14155/dialog"
HTTP/1.1 404 Not Found
Connection: Keep-Alive
Content-Length: 34
Content-Encoding: application/json
Date: Fri, 13 Jul 2018 05:37:42 GMT

{ "error" : "No dialog is open" }

Text Mode (Ncurses UI) Support

This is the most significant change, now the ncurses texmode UI also supports the embedded REST Server!

So you can see the updated Cucumber test used for testing in the Qt UI from the last HackWeek running in the text mode!

The only problematic part is that the Cucumber and YaST fight for the terminal output. That means we cannot run the YaST module directly but use some wrapper. In this case we run it in a new xterm session. But for the real automated tests it would be better to run it in a screen or tmux session in background so it works also without any X server.

Also some more complex scenarios work in the text mode, like a complete openSUSE Leap 15.0 installation running inside a VirtualBox VM:

In theory the REST API should work the same way in both graphical and text mode, from the outside you should not see a difference. Unfortunately in reality there are some differences you need to be aware…

The Text Mode Differences

Some differences are caused by the different UI implementation - like the Ncurses UI does not implement the Wizard widget and the main window has different properties. For example the main navigation buttons like Back or Next have YPushButton class in the text mode but in the graphical mode they have YQWizardButton class and the dialog content is wrapped in an additional YWizard object.

Another difference might be that YaST (or the libyui application in general) might display a different content in the graphical mode and in the text mode. For example the YaST time zone selection displays a nice clickable map in the graphics mode:

Obviously the world map cannot be displayed in the text mode:

But the bigger difference is that in the graphical mode the time zone is selected using the ComboBox widgets while in the text mode there are SelectionBox widgets!

What is Still Working :smiley:

The original support for generic libyui applications is still present. That means the REST API is not bound to YaST but can be used by any libyui application.

Here is a test for the libyui ManyWidgets example which is a standalone C++ application not using YaST at all:

Prepared Testing Packages

If you want to test this libyui feature in openSUSE Leap 15.0 then you can install the packages from the home:lslezak:libyui-rest-api OBS project. See more details here.

Sources

The source code is available in the http_server branches in the libyui/libyui, libyui/ncurses and libyui/qt Git repositories.

TODO

There are lots of missing things, but the project is becoming more usable for the basic application testing.

The most important missing features:

• Trigger notify or immediate events - if a widget with these properties is changed via the API these UI events are not created. Which usually means after changing a widget via the API the dialog is not updated as when the change is done by user.
• Authentication support
• Move the web server to a separate plugin so it is an optional feature which can be added only when needed
• SSL (HTTPS) support
• IPv6 support
• and many more…

I will continue with the project at the next HackWeek if possible…

I just followed this medium post, but long story short:

Check out the origin/master branch and make sure my local master, is equal to origin, then push it to my fork (I seldomly do git pull on master).

 git fetch origin
 git checkout master
 git reset --hard origin/master
 git push foursixnine

I needed to add the remote that belongs to a complete different repository:

 git remote add acarvajal gitlab@myhost:acarvajal/openqa-monitoring.git
 git fetch acarvajal
 git checkout -b merge-monitoring
 git merge acarvajal/master --allow-unrelated-histories

Tadam! my changes are there!

Since I want everything inside a specific directory:

 mkdir openqa/monitoring
 git mv ${allmyfiles} openqa/monitoring/

Since the unrelated repository had a README.md file, I need to make sure that both of them make it into the cut, the one from my original repo, and the other from the new unrelated repo:

Following command means: checkout README.md from acarvajal/master.

 git checkout acarvajal/master --  README.md
 git mv README.md openqa/monitoring/

Following command means: checkout README.md from origin/master.

 git checkout origin/master --  README.md

Commit changes, push to my fork and open pull request :)

 git commit
 git push foursixnine

Using Port Forwarding with xinetd has served me well at many occasions. As time proceeds, new technologies show up that allow for similar functionality and others are deprecated. When reading about the obsoletion of xinetd in SLES15, I wondered if you could do the port forwarding also with systemd instead of xinetd.

To accomplish the same port forwarding like in Port Forwarding with xinetd you can proceed as follows.

With systemd, the procedure is twofold. First you have to create a socket that listens on a stream. The second part is to start a proxy service that connects to a remote port. Both are connected by means of their respective name

/etc/systemd/system/http-switch.socket
/etc/systemd/system/http-switch.service

Just sticking with the previous example, let me use the following:

• the private has the IP address range 192.168.10.0/24
• the switch is configured with 192.168.10.254 and its management port is 80
• the jump host with access to both networks has the external address 10.10.10.1
• use port 81 to access the switch over the jump host

The first thing we need is a .socket file:

# cat /etc/systemd/system/http-switch.socket
[Socket]
ListenStream=10.10.10.1:81

[Install]
WantedBy=sockets.target

This socket must be connected to a proxy by means of the service name:

# cat /etc/systemd/system/http-switch.service
[Unit]
Description=Remote Switch redirect
Requires=network.target
After=network.target

[Service]
ExecStart=/usr/lib/systemd/systemd-socket-proxyd 192.168.10.254:80

[Install]
WantedBy=multi-user.target

After adding these files, the service can be enabled and started with the following commands:

systemctl enable http-switch.socket
systemctl enable http-switch.service
systemctl start http-switch.socket
systemctl start http-switch.service

The previous example is just a very basic one. Especially with the socket file, there is lots and lots of parameters and options available. For more information, see

man 5 systemd.socket
man 5 systemd.service

Dual Head, Multi-monitor

If you have two monitors attached to your computer then the setup is called dual head, the generic term for any number of monitors is multi-monitor.

This setup useful if a single monitor is not enough to show all needed windows at one. I use this setup for development where on the primary screen I have an editor or IDE running and on the second I have IRC chat, documentation, running virtual machines, etc… so I do not need to switch windows to see them.

But in this setup both monitors can used only one person at the same time.

Dual Seat or Multi Seat

If you have two monitors what about attaching one more keyboard and mouse and “split” the computer in half and have independent sessions for each user? That setup is called dual seat or multi seat in general.

Linux is a multi user systems from the very beginning. But normally these users either work remotely or they simply share one seat and need to cooperate who will use the computer when.

Hardware

For this multi seat solution you need a separate graphics adapter for each seat. Fortunately to to save some money you can combine discrete graphics cards with an integrated one. In my case I used an integrated Intel graphics adapter and a discrete AMD Radeon card.

If you use an integrated card you might need to enable the multi graphics support in BIOS because usually when a discrete graphics card is found the integrated one is disabled. In my case I had to enable the Multi-Monitor option in the BIOS:

Linux

I wanted to configure a multi seat already in the past, but it was really complicated. I would have to tweak the X.org config manually and there were lots of hacks.

But actually it turned out that using a modern Linux distribution like openSUSE Leap 15.0 makes this very easy!

Using the loginctl Tool

As in almost all modern Linux distributions also in the openSUSE Leap 15.0 the console is managed by the systemd login manager. To interact with it from the command line you can use a tool called loginctl.

It can handle the sessions, seats and users. Let’s see which seats are defined by default:

# loginctl list-seats
SEAT
seat0

1 seats listed.

Now we can list all hardware devices assigned to that seat:

# loginctl seat-status seat0
seat0
        Sessions: *5
         Devices:
                  ├─/sys/devices/LNXSYSTM:00/LNXPWRBN:00/input/input1
                  │ input:input1 "Power Button"
                  ├─/sys/devices/LNXSYSTM:00/LNXSYBUS:00/PNP0A08:00/LNXVIDEO:00/input/input2
                  │ input:input2 "Video Bus"
                  ├─/sys/devices/LNXSYSTM:00/LNXSYBUS:00/PNP0C0C:00/input/input0
                  │ input:input0 "Power Button"
                  ├─/sys/devices/pci0000:00/0000:00:01.0/0000:01:00.0/drm/card0
                  │ [MASTER] drm:card0
                  │ ├─/sys/devices/pci0000:00/0000:00:01.0/0000:01:00.0/drm/card0/card0-DP-1
                  │ │ [MASTER] drm:card0-DP-1
                  │ ├─/sys/devices/pci0000:00/0000:00:01.0/0000:01:00.0/drm/card0/card0-DVI-D-1
                  │ │ [MASTER] drm:card0-DVI-D-1
                  │ └─/sys/devices/pci0000:00/0000:00:01.0/0000:01:00.0/drm/card0/card0-HDMI-A-3
                  │   [MASTER] drm:card0-HDMI-A-3
                  ├─/sys/devices/pci0000:00/0000:00:01.0/0000:01:00.0/drm/renderD128
                  │ drm:renderD128
                  ├─/sys/devices/pci0000:00/0000:00:01.0/0000:01:00.0/graphics/fb0
                  │ [MASTER] graphics:fb0 "amdgpudrmfb"
...

Obviously all are devices are assigned to the only seat defined in the system.

Creating a New Seat

Persistence

The configuration is persistent, the attached devices are remembered and automatically set after reboot. You do not need to assign the devices after each reboot.

Drawback

There is one drawback of enabling the multi seat feature - the multi head setup does not work anymore. :worried:

To make it work back you would have to reconnect the monitors back to the same card and move the assigned devices back to the original seat. That’s quite annoying but you could possibly automate the monitor connection by and automatic HDMI switch if you use HDMI (or DVI) for connecting the monitors.

The Use Case: Minecraft! :smiley:

To avoid arguing who will play Minecraft right now you can simply enable running two Minecrafts in separate sessions!

It’s not obvious from the picture, but there is only one computer below the table!

Screenshot showing HTTP referer.

Consider a web page with URL α on web server A containing a link to a web page with URL β on web server B. If a web page visitor clicks on the link to β, many browsers send along with the request to server B for the web page β the referring webpage α. This information is sent in form of a HTTP request header.

Example Request with Referer Header

To illustrate this behaviour, let us assume you browse e.g. an adult-content web page β called https://newborn.xx/videos/some_video and click on a link to α that is https://blog.riemann.cc/digitalisation/2018/06/27/http-referer-and-data-protection/. Then, the HTTP request generated by your browser to download and display the webpage may contain the following fields:

Host: blog.riemann.cc
User-Agent: Mozilla/5.0 (X11; Linux x86_64; rv:60.0) Gecko/20100101 Firefox/60.0
Accept: text/html,application/xhtml+xml,application/xml;q=0.9,*/*;q=0.8
Accept-Language: en-GB,en;q=0.8,de-DE;q=0.5,de;q=0.3
Referer: https://newborn.xx/videos/some_video
DNT: 1

Host

A web server may serve more than one website. Hence, a host must be given to specify the requested webpage β.

User-Agent

The request contains information on the employed browser. Some servers may respond with a different, simplified webpage for e.g. outdated browsers.

Accept

The request contains information on response formats the browser could understand and display.

Accept-Language

The request contains information on the preferred languages of the response. This setting reflects the language setting of the browser or operating system.

Referer [sic]

It is actually a spelling mistake of the word referrer. The referring web page containing the link is provided.

DNT (do not track)

Modern browsers notify the web servers if the visitor wishes to not be tracked.

Impact on Privacy

If the request for β to the web server B contains the Referer field, then B learns which web page the visitor has visited before, i.e. https://newborn.xx/videos/some_video in the example above. Furthermore, B learns that this referring web page contains the link to β.

The impact on the visitor privacy is mentioned in the standard RFC 7231 Section 5.5.2:

The Referer field has the potential to reveal information about the request context or browsing history of the user, which is a privacy concern if the referring resource’s identifier reveals personal information (such as an account name) or a resource that is supposed to be confidential (such as behind a firewall or internal to a secured service). Most general-purpose user agents do not send the Referer header field when the referring resource is a local “file” or “data” URI. A user agent MUST NOT send a Referer header field in an unsecured HTTP request if the referring page was received with a secure protocol.

Also the documentation portal of Firefox has a notice on its web page to the Referer field.

The Referer header has the potential to reveal information about the browsing history of the user, which is a privacy concern.

According to the recommendation of the RFC standard, Firefox does not send a Referer field when:

1. the referring resource is a local “file” or “data” URI,
2. an unsecured HTTP request is used and the referring page was received with a secure protocol (HTTPS).

That means, if e.g. https://newborn.xx/videos/some_video contains a link to another HTTPS web page, the Referer field is sent.

Good Data Protection Practice

Not all, if not most, visitors do not understand that their browser sends a Referer field revealing a small part of their browsing history. In consequence, those visitors cannot give an informed consent. I remember how I installed my browser to identify a potential contractual legal basis.

My Linux operating system comes with Firefox pre-installed. During the installation of Linux, I confirm varying free software licenses that are all somewhat compatible to each other in one go (one click).

Firefox is provided under the terms of the Mozilla Public License. It contains an explicit Disclaimer of Warranty.

Covered Software is provided under this License on an “as is” basis, without warranty of any kind, either expressed, implied, or statutory, including, without limitation, warranties that the Covered Software is free of defects, merchantable, fit for a particular purpose or non-infringing. The entire risk as to the quality and performance of the Covered Software is with You. Should any Covered Software prove defective in any respect, You (not any Contributor) assume the cost of any necessary servicing, repair, or correction. […]

It is yet to be answered if a) the referer information constitutes personal data and b) the sharing of it (potentially among different parties on different continents) is covered on the basis of the browser license.

Independently of the answer, I think a much better practice would be to allow visitors to switch this sharing by their browser on and off. From a data minimisation point of view, no sharing should occur by default.

Interestingly, a bug has been filed in 2013 already:
(Regression) Data leak: HTTP-Referer sent when it should not be sent

This bug makes though a different assumption on when a Referer field should be sent. Consequently, I created a new bug report:
Data leak: HTTP-Referer sent without consent

Let us see what happens. :blush:

Update (2018-06-28)

While we wait for a comfortable user interface to disable the referer field, one can change the configuration of Firefox manually. I found the solution at a Mozilla Support page.

1. In a new tab, type or paste about:config in the address bar and press Enter/Return. Click the button promising to be careful.
2. In the search box above the list, type or paste referer and pause while the list is filtered
3. Double-click the network.http.referer.XOriginPolicy preference and enter the desired value:
